MSI PRO B760-P II DDR5 Intel LGA 1700 ATX Motherboard
Upgrade your computer setup with the MSI PRO B760-P II DDR5 Intel LGA 1700 ATX Motherboard. This high-performance motherboard is designed for gamers and professionals alike, featuring advanced DDR5 memory support and cutting-edge Intel LGA 1700 socket compatibility. With its ATX form factor, you'll have plenty of space for expansion and customization. Get ready to experience lightning-fast speeds and seamless processing power with this top-of-the-line motherboard from MSI. Elevate your computing experience with the MSI PRO B760-P II DDR5 Intel LGA 1700 ATX Motherboard.
£169.14
£140.95
SKU
012-805-865
In stock
Features
Description
Specification
Features
General
| SKU | 012-805-865 |
Features
| Brand | MSI |
| Model Number | PRO B760-P II |
| Motherboard Chipset | B760 Chipset (LGA 1700) |
| CPU Socket Type | LGA 1700 |
| Memory Type | DDR5 |
| Outputs | DisplayPort 1.4, HDMI 2.1 |
| Form Factor | ATX |
| Key Features |
|
Description
MSI PRO B760-P II DDR5 Intel LGA 1700 ATX Motherboard
Control in One Click
MSI Motherboards let you manager speeds and temperatures for all your system and CPU fans in BIOS and software with a simplified graphical interface. You can also set up to 4 temperatures targets, which will adjust the fan speeds automatically
Frozr AI Cooling
Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI Engine
Auto Detect Your Fan
MSI fan headers automatically detecs fans running in DC or PWM mode for optimal tuning of fan speeds and silence. Hysteresis also makes your fans spin up fluently to make sure your system stays silent, no matter what
12 + 1 + 1 Power Design
Unleash and sustain the maximum performance with a VRM design built with a total of 12 + 1+ 1 power design. Combining dual power connectors and exclusive core boost technology, PRO series motherboard is ready to sustain heavy daily work
Optimized PCB solution
The PCB design has been optimized for higher bandwidth and faster transfer speeds, which is also beneficial for reliable circuit transmission
Driver Utility Installer
Once connected to the internet, MSI Driver Utility Installer will detect and present suitable drivers and utilities automactically, you can download and install with just a few clicks Learn More
Fast and Future-Ready Storage
MSI PRO series motherboard support all the lastest storage standards, which allows users to connect any ultra-fast storage device. Start games faster, load levels faster and have a real advantage over your enemies.
Double Bandwidth with Lightning USB 70GBPS
Using USB devices has never been faster! MSI PRO series motherboards offer a wide variety of options to connect and boost your USB devices, offering never before seen USB speeds up to 10Gb/s when connecting the Rear USB Type-C
USB Front Type-C
MSI PRO motherboards support USB Front Type-C that allows gamers to connect with the lastest USB devices. Built up a system with MSI PC case to have the most convenient experience
Latest DDR5 Memory with SMT Slot
A huge step with DDR performance enhancement with the lastest DDR5 memory. Combines with dedicated SMT welding process and MSI memory Boost technology, MSI PRO series motherboards are ready to deliver the world class memory performance.
System Safety
All MSI PRO series motherboards have SECURITY function in BIOS to protect every private files for no matter business or daily use
The Isolated Analogy Structure for Audio Connectors
To provide clear voice, MSI develops a unique structure- Isolated Analogy Structure. The external metal framework of the audio connectors is seperated from the internal layout, which ensures the sound quality crisp
Extend your RGB experience with ease
Add more colour if you want! Mystic Light Extension pin header provides an intuitive way to control additional RGB strips and other RGB peripherals added to a system without needing a seperate RGB controller.
High-Bandwidth and Low-latency network
MSI's premium network solution provides incredible data transfer speed for demanding users
Specification
CHIPSET
INTEL B760
CPU
Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
LGA 1700
MEMORY
4x DDR5, Maximum Memory Capacity 256GB
Memory Support 7000+(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7000+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
• 2DPC 1R Max speed up to 6000+ MHz
• 2DPC 2R Max speed up to 5600+ MHz
Supports Intel® XMP 3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory
AUDIO
Realtek® ALC897 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
STORAGE
2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
4x SATA 6G
LAN
Realtek® RTL8125BG 2.5G LAN
ONBOARD GRAPHICS
1x HDMI™
Support HDMI™ 2.1, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 4K 60Hz*
*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
SLOT
5x PCI-E x16 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset)
RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
USB
2x USB 2.0 (Rear)
4x USB 2.0 (Front)
2x USB 5Gbps Type A (Rear)
4x USB 5Gbps Type A (Front)
1x USB 5Gbps Type C (Front)
1x USB 10Gbps Type C (Rear)
INTERNAL IO
1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
5x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
1x TBT connector (JTBT, supports RTD3)
2x Addressable V2 RGB LED connector (JARGB_V2)
2x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
4x USB 5Gbps Type A ports
1x USB 5Gbps Type C ports
LED FEATURE
4x EZ Debug LED
BACK PANEL PORTS
DisplayPort
2.5G LAN
USB 2.0
Audio Connectors
HDMI™
USB 5Gbps (Type-A)
USB 10Gbps (Type-C)
S/PDIF-OUT
OPERATING SYSTEM
Support for Windows® 11 64-bit, Windows® 10 64-bit
PCB INFO
ATX
243.84mmx304.8mm
