Thermaltake Toughpower GF3 1650W 80+ Gold Rated Fully Modular ATX 3.0 PCIe 5.0 Power Supply - PS-TPD-1650FNFAGE-4
Special Price
£244.99
£204.16
was
£301.14
SKU
AA5-D68-FF2
Out of stock
Features
Description
Specification
Features
General
| SKU | AA5-D68-FF2 |
Features
| Brand | Thermaltake |
| Model Number | PS-TPD-1650FNFAGE-4 |
| Wattage | 1650W |
| Efficiency Rating | 80+ |
| Modular? | Yes |
| PSU Form Factor | ATX |
| Colour | Black |
Description
Designed with a native PCIe 12+4pin connector, the Toughpower GF3 series is compatible with Intel ‘s ATX 3.0 specification and is built for next-gen PCIe 5.0 graphics cards.
The wattage marked on 12VHPWR’s connector is the recommended wattage. (Ref. Intel design guideline) The native 16 PIN (12VHPWR) PCIe connector of GF3 1650W can deliver up to 600W for PCIe 5.0 graphics cards.
Note: Recommended wattage is an estimation of system power demand. Actual power demands may vary based on specific components, usage, and many other factors.
Specification
P/N
PS-TPD-1650FNFAGE-4
WATTS
1650W
MODEL
TPD-1650AH3FSG
MAX. OUTPUT CAPACITY
1650W
COLOR
Black
DIMENSION ( W / H / D )
150mm(W) x 86mm(H) x 180mm(D)
WEIGHT
2.14 KG
PFC (POWER FACTOR CORRECTION)
Active PFC
POWER GOOD SIGNAL
100-250 msec
INPUT CURRENT
20 – 16A
INPUT FREQUENCY RANGE
50-60Hz
INPUT VOLTAGE
100 – 240V~
OPERATING TEMPERATURE
0°C to + 50°C
OPERATING HUMIDITY
20% to 90%,non-condensing
STORAGE TEMPERATURE
-40°C to + 70°C
STORAGE HUMIDITY
20% to 95%, non-condensing
COOLING SYSTEM
14cm hydraulic bearing fan
EFFICIENCY
Meet 80 PLUS®Gold at 115Vac input.
MTBF
100,000 hrs minimum
SAFETY APPROVAL
CE/UKCA/cTUVus/TÜV/FCC/IC/BSMI/EAC/CB/BIS/KCC
PCI-E 6+2PIN
9
PCIE 12+4PIN
2
