Thermaltake Toughpower GF3 750W 80+ Gold Rated Fully Modular ATX 3.0 PCIe 5.0 Power Supply - PS-TPD-0750FNFAGE-4
Special Price
£98.95
£82.46
was
£133.14
SKU
4A6-FB5-E9C
Out of stock
Features
Description
Specification
Features
General
| SKU | 4A6-FB5-E9C |
Features
| Brand | Thermaltake |
| Model Number | PS-TPD-0750FNFAGE-4 |
| Wattage | 750W |
| Efficiency Rating | 80+ |
| Modular? | Yes |
| PSU Form Factor | ATX |
| Colour | Black |
Description
Designed with a native PCIe 12+4pin connector, the Toughpower GF3 series is compatible with Intel ‘s ATX 3.0 specification and is built for next-gen PCIe 5.0 graphics cards.
The wattage marked on 12VHPWR’s connector is the recommended wattage. (Ref. Intel design guideline) The native 16 PIN (12VHPWR) PCIe connector of GF3 750W can deliver up to 300W for PCIe 5.0 graphics cards.
Note: Recommended wattage is an estimation of system power demand. Actual power demands may vary based on specific components, usage, and many other factors.
Specification
P/N
PS-TPD-0750FNFAGE-4
WATTS
750W
MODEL
TPD-0750AH3FCG
MAX. OUTPUT CAPACITY
750W
COLOR
Black
DIMENSION ( W / H / D )
150mm(W) x 86mm(H) x 160mm(D)
WEIGHT
1.63 KG
PFC (POWER FACTOR CORRECTION)
Active PFC
POWER GOOD SIGNAL
100-150 msec
HOLD UP TIME
> 17msec at 100% of full load
INPUT CURRENT
10.0A / 5.0A
INPUT FREQUENCY RANGE
50/60Hz
INPUT VOLTAGE
100V – 240V~
OPERATING TEMPERATURE
0°C to + 40°C
OPERATING HUMIDITY
20% to 90%,non-condensing
STORAGE TEMPERATURE
-20°C to + 70°C
STORAGE HUMIDITY
5% to 95%, non-condensing
COOLING SYSTEM
13.5cm fluid bearing fan
EFFICIENCY
Meet 80 PLUS®Gold at 115Vac input.
MTBF
100,000 hrs minimum
SAFETY APPROVAL
CE/UKCA/cTUVus/TÜV/FCC/IC/BSMI/EAC/CB/CCC
PCI-E 6+2PIN
PCIe 6+2Pin X 4
PCIe 12+4Pin X 1
PROTECTION
OCP, OVP, UVP, OPP, SCP, OTP
