AMD Ryzen 9 7900X3D Twelve Core 5.6GHz Processor, Gigabyte B650 Gaming X AX V2 Motherboard CPU Bundle
Achieve unparalleled computing performance with the AMD Ryzen 9 7900X3D 12-Core 5.6GHz Processor, paired with the advanced Gigabyte B650 Gaming X AX Motherboard. Featuring AMD's 3D V-Cache technology, PCIe 4.0 support, and superior thermal management, this bundle ensures exceptional multi-threading and peak gaming efficiency for demanding applications
Features
General
SKU | 7B7-3D4-066 |
Features
Brand | AWD-IT |
Model Number | ryzen97900x3d-gigabyteb650 |
Warranty Support | 3 Years |
Chipset | B650 |
CPU Socket Type | AM5 |
Memory Type | DDR5 |
CPU Series | Ryzen 7000 Series |
CPU Range | AMD Ryzen 9 |
CPU Model | Ryzen 9 7900X3D |
Number of Cores | 12 |
Number of Threads | 24 |
CPU Base Clock | 4.4GHz |
CPU Boost Clock | 5.6GHz |
Cache | 140MB |
Description


AMD Ryzen 9 7900X3D Twelve Core 5.6GHz Processor
With a maximum clock speed of 5.6GHz, this processor is designed to handle even the most demanding tasks with ease. Whether you're a gamer, content creator, or power user, this processor will take your computing experience to the next level.
Featuring twelve cores and 24 threads, the Ryzen 9 7900X3D is capable of handling heavy multitasking with ease. You can run multiple applications simultaneously without worrying about lag or slowdowns. From gaming to video editing, this processor can handle it all.
With AMD's advanced Zen 3 architecture, the Ryzen 9 7900X3D offers improved performance and efficiency compared to previous generations. You'll experience faster load times, smoother gameplay, and quicker rendering speeds, allowing you to get more done in less time.
The Ryzen 9 7900X3D also features AMD's Precision Boost 2 technology, which dynamically adjusts the processor's clock speed to maximize performance based on workload. This means you'll always have the power you need, exactly when you need it.
Additionally, the Ryzen 9 7900X3D supports PCIe 4.0, the latest standard in high-speed data transfer. This means you can take advantage of faster SSDs, graphics cards, and other peripherals for a smoother computing experience.
Twelve cores and 24 threads for unmatched multitasking performance
5.6GHz maximum clock speed for lightning-fast processing
Advanced Zen 3 architecture for improved performance and efficiency
Precision Boost 2 technology for dynamic clock speed adjustments
PCIe 4.0 support for high-speed data transfer
Gigabyte B650 Gaming X AX
Packed with innovative features and cutting-edge technology, this motherboard is designed to take your gaming experience to the next level. Powered by the latest Intel B650 chipset, the Gigabyte B650 Gaming X AX supports 10th and 11th Gen Intel Core processors, ensuring smooth and efficient performance. Equipped with dual-channel DDR4 memory support, you can enjoy lag-free gaming and multitasking with ease.
The Gigabyte B650 Gaming X AX features PCIe 4.0 support, providing lightning-fast data transfer speeds for your high-performance graphics cards and storage devices. With support for the latest PCIe Gen 4 NVMe SSDs, you can enjoy faster load times and seamless gameplay.
Enjoy immersive gaming visuals with the Gigabyte B650 Gaming X AX's support for 4K resolution and HDR. With HDMI and DisplayPort connectivity options, you can connect multiple monitors for a truly immersive gaming experience.
Stay connected with the Gigabyte B650 Gaming X AX's built-in Wi-Fi 6E and Bluetooth 5.2 connectivity. With ultra-fast wireless speeds and enhanced Bluetooth compatibility, you can enjoy lag-free online gaming and seamless device connectivity.
Enhance your gaming experience with the Gigabyte B650 Gaming X AX's RGB Fusion 2.0 lighting control. Customize your motherboard's lighting effects with ease, creating a personalized gaming setup that reflects your unique style.
Optimize your gaming performance with the Gigabyte B650 Gaming X AX's Smart Fan 6 technology. With multiple temperature sensors and hybrid fan headers, you can ensure optimal cooling for your system, keeping temperatures in check during intense gaming sessions.


Specification
Motherboard Specs | CPU Specs |
CPU AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors |
Name AMD Ryzen™ 9 7900X3D Family Ryzen Series Ryzen 7000 Series |
Chipset AMD B650 |
Architecture Zen 4 |
Memory Support for DDR5 4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules |
# of CPU Cores 12 Multithreading (SMT) Yes # of Threads 24 |
Onboard Graphics Integrated Graphics Processor with AMD Radeon™ Graphics support 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
Max. Boost Clock Up to 5.6 GHz Base Clock 4.4 GHz |
Audio Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel |
L1 Cache 768 KB L2 Cache 12 MB L3 Cache 128 MB |
LAN Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Default TDP 120W |
Wireless Communication module Realtek® Wi-Fi 6E RTL8852CE WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard |
Processor Technology for CPU Cores TSMC 5nm FinFET Processor Technology for I/O Die TSMC 6nm FinFET |
Expansion Slots |
CPU Compute Die (CCD) Size 71mm² I/O Die (IOD) Size 122mm² |
Storage Interface CPU 2 x M.2 connectors (Socket 3, M key, type 25110/2280 support) (M2A_CPU/M2B_CPU) M2A_CPU connector supports PCIe 5.0(Note) x4/x2 SSD, M2B_CPU connector supports PCIe 4.0 x4/x2 SSD Chipset 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB) 4 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
Package Die Count 3 |
USB CPU 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel 1 x USB 3.2 Gen 1 port on the back panel CPU + USB 2.0 Hub:3 x USB 2.0/1.1 ports on the back panel Chipset 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports available through the internal USB headers |
AMD EXPO™ Memory Overclocking Technology Yes Precision Boost Overdrive Yes Curve Optimizer Voltage Offsets Yes AMD Ryzen™ Master Support Yes |
Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 2 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 1 x CPU cooler LED strip/RGB LED strip header 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x serial port header 1 x reset button 1 x reset jumper 1 x Clear CMOS jumper |
CPU Socket AM5 |
Back Panel Connectors 2 x SMA antenna connectors (2T2R) 1 x Q-Flash Plus button 1 x DisplayPort 1 x HDMI port 1 x USB Type-C® port, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 2 Type-A port (red) 3 x USB 3.2 Gen 1 ports 3 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
Supporting Chipsets A620 , X670E , X670 , B650E , B650 Supported Extensions AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
I/O Controller iTE® I/O Controller Chip |
Max. Operating Temperature (Tjmax) 89°C |
H/W Monitoring Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control |
Native USB 3.2 Gen 2 (10Gbps) Ports 4 Native USB 3.2 Gen 1 (5Gbps) Ports 0 Native USB 2.0 (480Mbps) Ports 1 Native SATA Ports 0 |
BIOS 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
PCI Express® Version PCIe® 5.0 |
Operating System Support for Windows 11 64-bit Support for Windows 10 64-bit |
NVMe Support Boot , RAID0 , RAID1 , RAID10 |
Form Factor ATX Form Factor; 30.5cm x 24.4cm |
System Memory Type DDR5 |
Memory Channels 2 |
|
Max. Memory 128 GB |
|
System Memory Subtype UDIMM |
|
Max Memory Speed 2x1R DDR5-5200 2x2R DDR5-5200 4x1R DDR5-3600 4x2R DDR5-3600 |
|
ECC Support Yes (Requires mobo support) |
|
Graphics Model AMD Radeon™ Graphics |
|
Graphics Core Count 2 |
|
Graphics Frequency 2200 MHz |
|
USB Type-C® DisplayPort™ Alternate Mode Yes |
