Asus Prime B660M-A D4-CSM mATX Intel LGA 1700 Motherboard
Introducing the Asus Prime B660M-A D4-CSM, a high-performance and feature-packed motherboard designed for gamers and creators. With support for 12th Gen Intel Core processors, PCIe 4.0, and Thunderbolt 4 technology, this motherboard delivers exceptional speed and connectivity. Its durable construction and comprehensive cooling options ensure reliable performance, while ASUS BIOS Flashback simplifies firmware updates. The Prime B660M-A also boasts advanced security features and comprehensive management facilities, making it an ideal choice for business use. Upgrade your PC build with this SEO-optimised, SEO-enhanced motherboard designed for exceptional performance and reliability. Elevate your gaming and productivity experience with the Asus Prime B660M-A D4-CSM motherboard.
£82.30
£68.58
SKU
113-50B-FC4
Out of stock
Features
Description
Specification
Features
General
| SKU | 113-50B-FC4 |
Features
| Brand | Asus |
| Model Number | B660M-A D4-CSM |
| Warranty Support | 3 Years |
| Motherboard Chipset | B660 Chipset (LGA 1700) |
| CPU Socket Type | LGA1700 |
| Memory Type | DDR4 |
| Outputs | DisplayPort 1.4, HDMI |
Description
Asus Prime B660M-A D4-CSM mATX Intel LGA 1700 Motherboard
Upgrade your computer setup with the Prime B660M-A D4-CSM. Designed for Intel LGA 1700 processors, this mATX motherboard is a powerhouse when it comes to delivering top-notch performance for all your computing needs. With its innovative features and reliable construction, this motherboard is an ideal choice for both gamers and professionals alike.
Equipped with the latest technology, the Asus Prime B660M-A D4-CSM boasts support for DDR4 memory and PCIe 5.0, ensuring lightning-fast speeds and seamless multitasking. The motherboard also features USB 3.2 Gen 2 Type-A and Type-C ports, allowing for quick and hassle-free data transfers. Additionally, its comprehensive cooling solutions ensure that your system stays cool even during extended gaming sessions or intensive workloads.
When it comes to connectivity, the Prime B660M-A D4-CSM has you covered. With support for HDMI, DisplayPort, and DVI outputs, this motherboard offers versatile display options for all your visual needs. Whether you're gaming, editing videos, or simply browsing the web, you can count on this motherboard to deliver sharp and vibrant visuals every time.
Asus understands the importance of reliability and durability, which is why the Prime B660M-A D4-CSM is built to last. With its sturdy construction and premium components, this motherboard is designed to withstand the test of time, ensuring long-term stability and performance for your computer system.
In addition to its impressive performance capabilities, the Asus Prime B660M-A D4-CSM is also designed with user convenience in mind. Its user-friendly BIOS interface and intuitive software make it easy to customize your system settings and optimize performance according to your specific requirements. Whether you're a beginner or an experienced enthusiast, you'll appreciate the simplicity and flexibility that this motherboard offers.
When it comes to upgrading your computer system, the Prime B660M-A D4-CSM is the perfect choice. Its combination of high-performance features, reliable construction, and user-friendly design make it a valuable addition to any setup. Whether you're a professional looking for a dependable workhorse or a gamer in need of seamless performance, this motherboard has what it takes to elevate your computing experience to the next level.
Specification
CPU
Intel® Socket LGA1700 for 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset
Intel® B660 Chipset
Memory
4 x DIMM, Max. 128GB, DDR4
5333(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem II
*Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Graphics
1 x DisplayPort**
2 x HDMI® ports***
* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
***Supports 4K@60Hz as specified in HDMI 2.1.
Expansion Slots
Intel® 13th & 12th Gen Processors
1 x PCIe 4.0/3.0 x16 slot
Intel® B660 Chipset *
1 x PCIe 3.0 x16 slot (supports x4 mode)
1 x PCIe 3.0 x16 slot (supports x1 mode)
*Supports Intel® Optane Memory H Series on PCH-attached PCIe slot
Storage
Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
Intel® 13th & 12th Gen Processors*
M.2_1 slot (Key M), type 2242/2260/2280
- Intel® 12th Gen processors support PCIe 4.0 x4 mode.
Intel® B660 Chipset**
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)*
4 x SATA 6Gb/s ports
* Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
** Intel® Rapid Storage Technology supports Intel® Optane Memory H Series on PCH attached M.2 slots.
Ethernet
1 x Intel® 1Gb Ethernet
ASUS LANGuard
USB
Rear USB:Total 6 ports
2 x USB 3.2 Gen 2 ports (2 x Type-A )
4 x USB 2.0 ports (4 x Type-A)
Front USB:Total 10 ports
2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports
1 x USB 3.2 Gen 1 connector (supports USB Type-C®)
2 x USB 2.0 headers support additional 4 USB 2.0 ports
1 x USB 2.0 header supports 1 USB 2.0 port
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Back Panel I/O Ports
2 x USB 3.2 Gen 2 ports (2 x Type-A )
4 x USB 2.0 ports (4 x Type-A)
1 x DisplayPort
2 x HDMI® ports
1 x Intel® 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port
Internal I/O Connectors
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
2 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports
1 x USB 3.2 Gen 1 connector (supports USB Type-C®)
2 x USB 2.0 headers support additional 4 USB 2.0 ports
1 x USB 2.0 header supports 1 USB 2.0 port
Miscellaneous
3 x AURA Addressable Gen 2 headers
1 x AURA RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x LPT header
1 x S/PDIF Out header
1 x SPI TPM header (14-1pin)
1 x 20-3 pin System Panel header with Chassis intrude function
BIOS
128 Mb Flash ROM, UEFI AMI BIOS
Manageability
WOL by PME, PXE
Accessories
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x I/O Shield
1 x M.2 Rubber Package
1 x M.2 SSD screw package
Installation Media
1 x Support DVD
Documentation
1 x User manual
Operating System
Windows® 11, Windows® 10 64-bit
Form Factor
microATX
24.4cm x 24.4cm
