Asus TUF GAMING X870-PLUS WIFI AMD Ryzen DDR5 Motherboard - Socket AM5 - 90MB1IU0-M0EAY0
The TUF GAMING X870-PLUS WIFI motherboard delivers exceptional performance for gamers and enthusiasts. With advanced cooling technology, robust power design, and dual-band Wi-Fi support, it ensures seamless connectivity and stability. Enjoy vibrant visuals with PCIe 5.0 and DDR5 memory support, making it a perfect choice for your high-performance gaming rig.
Special Price
£319.95
£266.62
was
£385.14
SKU
070-CEB-830
In stock
Features
Description
Specification
Features
General
| SKU | 070-CEB-830 |
Features
| Brand | Asus |
| Model Number | 90MB1IU0-M0EAY0 |
| Warranty Support | 2 Years |
| Chipset | AM5 |
| Memory Capacity | 192GB |
| Operating System | Windows 11 |
| Colour | Black |
| Key Features |
AMD AM5 socket support Compatible with Ryzen 7000 series processors Supports up to 195GB DDR5 RAM Dual-channel memory architecture PCIe 5.0 support for graphics and storage Wi-Fi 7 and Bluetooth 5.4 connectivity SupremeFX audio technology for immersive sound Robust power delivery with 16+2 DrMOS power stages Comprehensive cooling options including multiple fan headers RGB lighting customization with ASUS Aura Sync PCIe Q-Release for easy graphics card removal M.2 heatsinks for improved SSD thermal management User-friendly UEFI BIOS for easy configuration Durable construction with military-grade components |
Description
Asus TUF GAMING X870-PLUS WIFI AMD Ryzen DDR5 Motherboard - Socket AM5 - 90MB1IU0-M0EAY0
TUF GAMING X870-PLUS WIFI: Unleash Your Gaming Potential
The TUF GAMING X870-PLUS WIFI motherboard is engineered for serious gamers who demand performance and reliability. Built on the AMD X670 platform, this motherboard supports the latest AMD Ryzen processors, bringing powerful performance to your gaming rig. With robust features and cutting-edge technology, gamers can enjoy superior gaming experiences and dynamic multitasking capabilities.
Equipped with advanced thermal management, the TUF GAMING X870-PLUS WIFI ensures optimal performance even under heavy load. The comprehensive cooling solution includes large VRM heatsinks and multiple fan headers, allowing you to maintain peak performance during intense gaming sessions. Heat-resistant capacitors and military-grade components guarantee durability, ensuring the motherboard withstands long hours of gaming action.
The motherboard supports the latest PCIe 5.0 technology, providing faster data transfer speeds for next-gen graphics cards and storage devices. Gamers can take advantage of lightning-fast loading times and seamless gameplay, supported by Dual M.2 slots that allow you to install high-speed SSDs for ultimate storage flexibility. With support for up to 195GB of DDR5 memory, there's plenty of headroom for multitasking and running demanding applications.
Networking is a breeze with the TUF GAMING X870-PLUS WIFI. With integrated WiFi 7, you can enjoy high-speed wireless connectivity without the clutter of cables. Gigabit Ethernet ensures stable wired connections for competitive gaming, reducing latency and enhancing overall performance. Whether you prefer gaming via WiFi or Ethernet, this motherboard has you covered.
The user-friendly BIOS interface makes overclocking and system tuning accessible to all users. Fine-tune your settings, manage fan speeds, and monitor system health all in one place. The AI Overclocking feature intelligently adjusts performance based on system configurations, delivering optimal results without requiring extensive technical knowledge.
Further enhancing the gaming experience, the TUF GAMING X870-PLUS WIFI comes with customizable RGB lighting. Sync your motherboard with other ASUS Aura Sync-compatible devices for a coordinated, immersive gaming environment. Create stunning visual displays that reflect your gaming style as your build comes to life with vibrant colors.
With an extensive array of I/O ports, connectivity options, and expansion slots, this motherboard is designed for versatility. Connect all your peripherals and expand your capabilities without hassle. USB 3.2 Gen 2 ports offer rapid data transfer, while multiple USB Type-A and Type-C ports provide flexibility for various devices.
Designed with gamers in mind, the TUF GAMING X870-PLUS WIFI is not just a motherboard; it's a foundation for your gaming triumphs. With its robust build quality, advanced technology, and customization features, you can trust that your gaming rig will deliver outstanding performance. Ready to build your dream gaming setup? The TUF GAMING X870-PLUS WIFI is your ticket to a superior gaming experience.
Specification
Spec Sheet
Model
Name
TUF GAMING X870-PLUS WIFI
CPU Socket
AMD Socket AM5 for AMD Ryzen™ 9000, 8000, & 7000 Series Desktop Processors
Note
Refer to ASUS Support for CPU support list
Chipset Type
AMD X870 Chipset
Memory Slots
4 x DIMM slots, max. 192GB, DDR5
Supported Speeds
Up to 8000+ MT/s (OC) with Ryzen™ 9000, 8000, & 7000 Series Processors
Features
ECC and Non-ECC, Un-buffered DIMM, Dual channel memory architecture, Supports AMD EXPO™, ASUS Enhanced Memory Profile (AEMP)
Notes
Supported memory types, data rate, and number of DRAM modules vary depending on the CPU and memory configuration
Graphics Ports
1 x HDMI™ port (supports 4K@60Hz as per HDMI 2.1)
2 x USB4® (40Gbps) ports (USB Type-C® display outputs)
Expansion Slots
For AMD Ryzen™ 9000 & 7000 Series Desktop Processors: 1 x PCIe 5.0 x16 slot (supports x16 mode)
For AMD Ryzen™ 8000 Series Desktop Processors: 1 x PCIe 4.0 x16 slot (supports x8/x4 mode)
For AMD X870 Chipset: 1 x PCIe 4.0 x16 slot (supports x4 mode)
Storage
Total Slots: Supports 4 x M.2 slots and 2 x SATA 6Gb/s ports
For AMD Ryzen™ 9000 & 7000 Series Desktop Processors:
M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
For AMD Ryzen™ 8000 Series Desktop Processors:
M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot not supported
For AMD X870 Chipset:
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
2 x SATA 6Gb/s ports
Ethernet Port
1 x Realtek 2.5Gb Ethernet
Feature
TUF LANGuard
Wireless & Bluetooth
Wi-Fi
Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), supports 2.4/5/6GHz frequency band, up to 2.9Gbps transfer rate
Bluetooth
v5.4
Note
Wi-Fi and Bluetooth features may vary depending on the operating system
USB
Rear USB (Total 10 ports):
2 x USB4® (40Gbps) ports (2 x USB Type-C®)
3 x USB 10Gbps ports (3 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
1 x USB 2.0 port (1 x Type-A)Front USB (Total 7 ports):
1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD Fast-charge)
1 x USB 5Gbps header (supports 2 additional USB 5Gbps ports)
2 x USB 2.0 headers (supports 4 additional USB 2.0 ports)
Audio
Codec
Realtek ALC1220P 7.1 Surround Sound High Definition Audio
Features
Impedance sense for front and rear headphone outputs, Internal audio Amplifier, Jack-detection, Multi-streaming, Front Panel Jack-retasking, 120 dB SNR stereo playback output, 113 dB SNR
recording input (Line-in), Supports up to 32-Bit/192 kHz playback
Back Panel I/O Ports
Ports
2 x USB4® (40Gbps) (2 x USB Type-C®)
3 x USB 10Gbps ports (3 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
1 x USB 2.0 port (1 x Type-A)
1 x HDMI™ port
1 x Wi-Fi module
1 x Realtek 2.5Gb Ethernet port
5 x Audio jacks
1 x BIOS FlashBack™ button
Internal I/O Connectors
Fan and Cooling
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
1 x W_PUMP+ header
Power
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connectors
Storage
4 x M.2 slots (Key M)
2 x SATA 6Gb/s ports
USB
1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD Fast-charge)
1 x USB 5Gbps header (supports 2 additional USB 5Gbps ports)
2 x USB 2.0 headers (supports 4 additional USB 2.0 ports)
Miscellaneous
3 x Addressable Gen 2 headers
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x 10-1 pin Front System Panel header
1 x Thermal Sensor header
Special Features
ASUS TUF PROTECTION:
DIGI+ VRM (Digital power design with SPS)
ESD Guards
TUF LANGuard
Overvoltage protection
SafeSlot
Stainless-steel back I/O
ASUS Q-Design
M.2 Q-Latch
PCIe Slot Q-Release
Q-Antenna
Q-Dashboard
Q-DIMM
Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
Q-Slot
ASUS Thermal Solution:
M.2 heatsinks
VRM heatsink design
ASUS EZ DIY:
BIOS FlashBack™ button
BIOS FlashBack™ LED
ProCool
Pre-mounted I/O shield
SafeDIMM
Aura Sync:
Addressable Gen 2 headers
Front Panel USB 20Gbps with PD Fast Charge Support:
Supports up to 30W fast charging and USB Wattage Watcher
Output: 5V/9V max. 3A, 12V max. 2.5A, 15V max. 2A
Compatible with PD3.0
Software Features
ASUS Exclusive Software:
Armoury Crate
Aura Creator
Aura Sync
Fan Xpert 4 (with AI Cooling II)
Power Saving
ASUS DriverHub
ASUS GlideX
USB Wattage Watcher
TurboV Core
TUF GAMING CPU-Z
DTS Audio Processing
Norton 360 for Gamers (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
Features
AI Overclocking Guide
ASUS EZ DIY (CrashFree BIOS 3, EZ Flash 3, UEFI BIOS EZ Mode, MyHotkey)
Manageability
Features
WOL by PME, PXE
Accessories
Cables
2 x SATA 6Gb/s cables
