be quiet! Pure Base 500 Window Metallic Gray MIDI Tower Case - BGW36
be quiet! Pure Base 500 Window Metallic Gray combines customizable and silence features with a compact and sophisticated design.
Features


General
SKU | 7AC-BD2-3A3 |
Features
Brand | Be Quiet |
Model Number | BGW36 |
Warranty Support | 3 Years |
Colour | Titanium Grey |
Key Features | - Exchangeable top cover for silent or high-performance systems |
Description
be quiet! Pure Base 500 Window Metallic Gray MIDI Tower Case - BGW36
be quiet! Pure Base 500 Window Metallic Gray combines customizable and silence features with a compact and sophisticated design.
Perfect for silent air-cooled systems
The regular top cover perfectly rounds off the design of the Pure Base 500. An insulation mat attached underneath ensures a silent operation. It is the perfect choice for air-cooled systems and regular, silent PC configurations. Strong magnets make sure the top covers fits firmly.
Maximum airflow for water-cooled configurations
For all who strive for maximum performance and especially with water-cooled systems, the extremely air-permeable top cover is the right choice. It is made of light meshed fabrics, ensuring the highest airflow possible.
Whisper-quiet operation
Two preinstalled Pure Wings 2 fans with airflow-optimized fan blades that ensure perfect airflow and cooling. Despite the compact case design the front and rear fans are both 140mm models, resulting in very quiet operation. Up to three 140mm fans can be installed in addition.
Achieving great silence and stability
The front, sides and regular top cover are equipped with insulation mats that result in great stability and improved noise dampening capabilities. The dust filters on the front and bottom are easy to remove for cleaning.
Generous space for high-end hardware
The Pure Base 500 provides generous dimensions to install high-end graphics cards and large coolers of up to 190mm in height. Fans or a radiator up to 360mm can be installed easily at the front and the top area also provides space for more fans or a radiator up to 240mm.
Great cable routing possibilities
Pure Base 500 offers various possibilities for installing up to 5 SSDs in total. 2 can be installed for prominent viewing through the window panel. To hide any unwanted cables, the case offers excellent cable routing options.
A neat interior
The PSU shroud perfectly covers the cables and PSU. It also contains a double HDD cage with decoupled mountings that reduce vibrations and help maximize the silence. The cage can also be repositioned to install a radiator of up to 360mm at the front. The power supply unit can be easily installed from behind, mounted on the PSU bracket provided.
A perfect view inside your PC
The high-quality, fully-windowed side panel offers a perfect view of the components inside your PC case. The window is made of tempered glass with gray painted side bars.
Specification
General Data
Model: Pure Base 500 Window Metallic Gray
Color option: Gray
Motherboard compatibility: ATX / M-ATX / Mini-ITX
Case size excl. stands (L x W x H), (mm): 450 x 232 x 443
Case size incl. stands (L x W x H), (mm): 450 x 232 x 463
PSU form factor: ATX PS/2
Weight (kg): 7.53
Expansion slots: 7
Pre-installed Fans
Fan @ top: -
Fan @ front: 1x Pure Wings 2 140mm
Fan @ rear: 1x Pure Wings 2 140mm
Dimensions (L x W x H), (mm): Front: 140 x 140 x 25 / Rear: 140 x 140 x 25
Fan speed @ 100% PWM / 12V (rpm): 900
Airflow @ 100% PWM / 12V (CFM / m3/h): 55.8 / 94.8
Air Pressure @ 100% PWM / 12V (mm H2O): 0.6
Noise level @ 100% PWM / 12V (dB(A)): 17.1
Voltage range (V DC): 12
Input power (W): 1.08
Input current (A): 0.09
Connector: 3-Pin
Lifespan (h / 25°C): 80,000
Fan controller: -
Maximum Fan Installation
Top (mm): 2x 120 / 2x 140
Front (mm): 3x 120 / 2x 140
Rear (mm): 1x 140
Bottom (mm): -
Side panel (mm): -
PSU shroud: -
Optional Radiator Installation
Top (mm): 120 / 240
Front (mm): 120 / 140 / 240 / 280 / 360
Rear (mm): 120 / 140
Bottom (mm): -
PSU Compatibility
Maximum dimensions excl. bottom fan (mm): 258
Maximum dimensions incl. bottom fan (mm): 225
Graphics Card
HDD cage (in height of graphics card) installed (mm): 369
HDD cage (in height of graphics card) removed (mm): 369
Drive Bay Capacity
5.25 bays: -
3.5 slots (max.): 2
3.5 slots (scope of delivery): 2
2.5 slots (max.): 5
2.5 slots (scope of delivery): 5
Cooling
Max.construction height of CPU cooler unit (mm): 190
Airflow channel: Front / Top / Rear
Lighting
RGB LED illumination: -
LEDs synchronizable with RGB controller/motherboard: -
Expandable RGB controller: -
I/O Panel
USB 3.2 Gen. 2 Type C: -
USB 3.2 Gen. 1: 2
USB 2.0: -
HD Audio I/O: Mic + Audio
Qi charger / Quick Charging Option: -
Insulation and Damping
Top panel insulation mats: ✓
Front panel insulation mats: ✓
Side panel insulation mats: ✓
Anti-vibration decoupled HDD: ✓
Anti-vibration decoupled fan: -
Anti-vibration decoupled PSU: ✓
Anti-vibration decoupled motherboard-tray: -
Removeable Dust Filters
Front: 1
Bottom: 1
Side panel: -
Material
Top cover: ABS
Front panel: ABS
Side panel: Steel
Side panel window: 4mm tempered glass
Stands: ABS
