MSI B760M PROJECT ZERO Intel LGA 1700 Back-Connect WIFI 6E MicroATX Motherboard

With blazing fast WiFi 6E speeds with the MSI B760M PROJECT ZERO Intel LGA 1700 Motherboard. This MicroATX motherboard features back-connect WiFi, ensuring optimal signal strength and stability. With support for 11th and 12th Gen Intel processors, the B760M PROJECT ZERO offers exceptional performance for gaming and multitasking. Its sleek design and compact form factor make it perfect for smaller PC builds. Upgrade your system with this cutting-edge motherboard and enjoy seamless connectivity and powerful processing capabilities.

£204.95 £170.79
SKU
DB6-070-29C
In stock

Features

General

SKU DB6-070-29C

Features

Brand MSI
Model Number B760M PROJECT ZERO
Motherboard Chipset B760 Chipset (LGA 1700)
CPU Socket Type LGA1700
Memory Type DDR5
Outputs DisplayPort 1.4, HDMI 2.1
Form Factor Mini-ITX
Key Features
  • Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
  • Supports DDR5 Memory, up to 7800+(OC) MHz
  • Enhanced Power Design: 12+1+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost
  • Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2
  • Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
  • Audio Boost: Reward your ears with studio grade sound
  • High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material

Description

MSI B760M PROJECT ZERO Intel LGA 1700 Back-Connect WIFI 6E MicroATX Motherboard


This MicroATX motherboard is designed for Intel LGA 1700 processors, providing a seamless and high-performance computing experience. With its innovative Back-Connect WIFI 6E technology, you can enjoy ultra-fast wireless connectivity for all your online activities.

Featuring a sleek and modern design, the MSI B760M PROJECT ZERO is the perfect combination of style and functionality. Its compact MicroATX form factor makes it ideal for building small, yet powerful, systems without compromising on performance. Whether you're a gamer, content creator, or power user, this motherboard is built to meet your needs.

Equipped with the latest Intel LGA 1700 socket, this motherboard supports a wide range of Intel processors, allowing you to customize your system based on your specific requirements. Its advanced power delivery and thermal design ensure efficient and stable operation, even under heavy workloads or intense gaming sessions.

Designed with the needs of modern users in mind, the MSI B760M PROJECT ZERO offers a range of connectivity options, including USB 3.2 Gen 2 and Gen 1 ports, HDMI, and DisplayPort outputs, as well as support for dual-channel DDR4 memory. Whether you're connecting peripherals, external storage devices, or high-resolution displays, this motherboard has you covered.

When it comes to performance, the MSI B760M PROJECT ZERO motherboard delivers exceptional speed and efficiency. Its advanced WIFI 6E technology provides lightning-fast wireless connectivity, while the latest PCIe 4.0 support ensures blazing-fast data transfer speeds for your storage devices and graphics cards. Whether you're gaming, streaming, or multitasking, this motherboard is up to the task.

With its cutting-edge features and robust construction, the MSI B760M PROJECT ZERO is the perfect choice for anyone looking to build a high-performance, reliable, and future-proof system. Whether you're a casual user or a hardcore enthusiast, this motherboard is sure to impress with its unmatched performance and versatility.

Upgrade your computing experience with the MSI B760M PROJECT ZERO and take your system to the next level. With its advanced features, reliable performance, and sleek design, this motherboard is the perfect foundation for your next PC build.

"

Specification


CPU
Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
LGA1700

MEMORY
4x DDR5, Maximum Memory Capacity 256GB
Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7800+ MHz
• 1DPC 2R Max speed up to 6600+ MHz
• 2DPC 1R Max speed up to 6400+ MHz
• 2DPC 2R Max speed up to 5600+ MHz

Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile

ONBOARD GRAPHICS
1x HDMI™
Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 4K 60Hz*
*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

SLOT
2x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)

STORAGE
2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G

RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

LAN
Realtek® 2.5Gbps LAN

WIRELESS LAN & BLUETOOTH
Intel® Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth® 5.3, FIPS, FISMA
* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.
** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.

AUDIO
Realtek® ALC897 Codec
7.1-Channel High Performance Audio
Supports S/PDIF output

INTERNAL IO
1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
4x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x TBT connector (JTBT, supports RTD3)
1x Tuning Controller connector(JDASH)
2x Addressable V2 RGB LED connector (JARGB_V2)
2x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 3.2 Gen1 Type A ports
1x USB 3.2 Gen2 Type C ports

LED FEATURE
4x EZ Debug LED

Back Panel Ports
USB 2.0
DisplayPort 1.4
USB 3.2 Gen 2 10Gbps Type-A
2.5G LAN Port
Wi-Fi / Bluetooth Antenna
HD Audio Connectors
HDMI™ 2.1 Port
USB 3.2 Gen 2x2 20Gbps Type-C
Optical S/PDIF OUT

OPERATING SYSTEM

Support for Windows® 11 64-bit, Windows® 10 64-bit

PCB INFO
mATX
243.84mmx243.84mm
