MSI PRO Z790-S WIFI DDR5 Intel LGA 1700 ATX Motherboard

Experience next-level performance with the MSI PRO Z790-S WIFI DDR5 Intel LGA 1700 ATX Motherboard. This top-of-the-line motherboard boasts cutting-edge technology and unrivaled connectivity options, making it perfect for gamers, content creators, and professionals alike. With DDR5 memory support and built-in WiFi, you'll enjoy lightning-fast speeds and seamless multitasking. The ATX form factor ensures compatibility with a wide range of components, while the Intel LGA 1700 socket supports the latest generation of processors. Upgrade your system today and unleash the full potential of your rig with the MSI PRO Z790-S WIFI Motherboard.

£150.31 £125.26
SKU
A89-27C-0E3
Out of stock

Features

General

SKU A89-27C-0E3

Features

Brand MSI
Model Number PRO Z790-S WIFI
Motherboard Chipset Z790 Chipset (LGA 1700)
CPU Socket Type LGA1700
Memory Type DDR5
Outputs DisplayPort 1.4, HDMI
Form Factor ATX
Key Features
  • Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
  • Supports DDR5 Memory, Dual Channel DDR5 6600+MHz (OC)
  • Enhanced Power Design: 12+1+1 Duet Rail Power System with P-PAK, dual 8-pin CPU power connectors, Core Boost, Memory Boost
  • Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
  • High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material

Description

MSI PRO Z790-S WIFI DDR5 Intel LGA 1700 ATX Motherboard


Control In One Click
MSI Motherboards let you manage speeds and temperatures for all your system and CPU fans in BIOS and software with a simplidified graphical interface. You can also set up to 4 temperature targets, which will adjust the fan speeds automatically.

Frozr AI Cooling
Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI Engine

Optimised for Water Cooling
Designed to support the most popular all-in-one & customized eater cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked 'keep-out-zone' allows for easy and safe installation and a perfect fit

12+1+1 Power Design
Unleash and sustain the maximum performance with a VRM design built with a total of 12+1+1 power design. Combining dual power connectors and exclusive Core boost technology, MSI PRO Series motherboards are ready to sustain heavy daily work

Digital Power Design
A fully digital power design allows for faster and undistorted current delivery to the CPU at pin-point precision.

Optimised PCB Solution
The PCB design of 6 layers has been optimized for higher bandwidth and faster transfer speeds, which is also beneficial for reliable circuit transmission


Isolated Audio Signal

High Quality Audio Jacks

High Quality Audio Capacitors

High Definition Audio Processor

DE-POP Protection

Specification


CHIPSET
INTEL Z790

CPU
Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
LGA 1700

MEMORY
4x DDR5, Maximum Memory Capacity 256GB
Memory Support DDR5 6600+(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 6600+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
• 2DPC 1R Max speed up to 6000+ MHz
• 2DPC 2R Max speed up to 5600+ MHz

Supports Intel® XMP 3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory

AUDIO
Realtek® ALC897 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output

STORAGE
2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G

LAN
Realtek® RTL8125BG 2.5Gbps LAN

ONBOARD GRAPHICS
1x HDMI™
Support HDMI™ 1.4 with HDR, maximum resolution of 4K 30Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 4K 60Hz*
*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

SLOT
2x PCI-E x16 slot
3x PCI-E x1 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 3.0 supports up to x4 (From Chipset)
PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset)

RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

USB
2x USB 2.0 (Rear)
4x USB 2.0 (Front)
4x USB 5Gbps Type A (Rear)
4x USB 5Gbps Type A (Front)
1x USB 20Gbps Type C (Rear)

WIRELESS LAN & BLUETOOTH
Intel® Wi-Fi 6E
The Wireless module is pre-installed in the M.2_WIFI1 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth® 5.3, FIPS, FISMA

* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.
** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.

INTERNAL IO
1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
4x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x TBT connector (JTBT, supports RTD3)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
4x USB 5Gbps Type A ports

BACK PANEL PORTS
 DisplayPort
HDMI™
USB 2.0
USB 3.2 Gen 2x2 20Gbps (Type-C)
2.5G LAN
Audio Connectors
USB 3.2 Gen 1 5Gbps (Type-A)
USB 3.2 Gen 1 5Gbps (Type-A)
S/PDIF-OUT

OPERATING SYSTEM
Support for Windows® 11 64-bit, Windows® 10 64-bit

PCB INFO
ATX
243.84mmx304.8mm
