November 2, 2023

Translucent tempered glass panels on the front and side provide an unobstructed glimpse of your components, offering a seamless visual experience. The dual-chamber layout discreetly conceals the PSU and storage, resulting in an elegant, compact, and distinctive appearance.

The strategically positioned front-right corner features a trio of 120mm fans, precision-engineered to target components prone to heat buildup. Underneath the GPU, you'll find room for two 140mm fans, ensuring optimal cooling, while perforated panels work in harmony to augment and optimize airflow.

Experience top-tier performance with the H6 Flow. It supports a 360mm radiator up top and houses a 365mm GPU, delivering exceptional power and cooling while maintaining an elegant, modern design. Whether you're a gamer or a professional, it's ready to meet your demands.

The user-friendly layout of H6 Flow streamlines construction effortlessly, featuring spacious channels and bundled straps for efficient cable organization. Convenient, tool-free access to both the top and side panels simplifies adjustments and enhancements.

KEY SPECS

Motherboard Support: ATX, Micro-ATX, Mini-ITX

Enclosure Type: Mid-Tower

Case Material: SGCC Steel, Ultra-Clear Tempered Glass,
Dark Tinted Tempered Glass (Black SKU only)

DIMENSIONS

Height (with feet): 435 mm / 17.13 in

Width: 287 mm / 11.3 in

Depth: 415 mm / 16.34 in

Weight: 9.4 kg

COMPATIBILITY & CLEARANCE

CPU Cooler Height: 163 mm / 6.42 in

GPU Length: 365 mm / 14.37 in

PSU Length: 200 mm / 7.87 in

Cable Management: 91 mm / 3.58 in

Top Radiator: 30 mm / 1.18 in

FRONT I/O

USB 3.2 Gen 1 Type-A: 2

USB 3.2 Gen 2 Type-C: 1

Headset Audio Jack: 1

EXPANSION SLOTS

Standard: 7

Vertical: 0

DRIVE BAYS

2.5": 2

3.5": 1

FAN SUPPORT

Front-Right: 3 x 120 mm (3 x F120 RGB Core Fan Case Version)

Top: 3 x 120 mm / 2 x 140 mm

Bottom: 2 x 140 mm

Rear: 1 x 120 mm

Filters: High-Performance Mesh

RADIATOR SUPPORT

Top: Up to 360 mm

Rear: Up to 120 mm

FAN SPECS

Model: F120 RGB Core Fan (Case Version)

Speed: 1300 ± 130 RPM

Airflow: 55.17 CFM

Static Pressure: 1.27 mm-H2O

Noise: 26.1 dBA

Fan Connector: 3-Pin

GENERAL

Warranty: 2 Years

Model Number: CC-H61FW-R1 (White) / CC-H61FB-R1 (Black)

UPC: 810074844154 (White) / 810074844161 (Black)

EAN: 5056547204062 (White) / 5056547204079 (Black)

INSIDE THE BOX

H6 Flow: 1

F120 RGB Core Fan (Case Version): 3

Installation Accessories: 1

User Guide: 1

KEY SPECS

Motherboard Support: ATX, Micro-ATX, Mini-ITX

Enclosure Type: Mid-Tower

Case Material: SGCC Steel, Ultra-Clear Tempered Glass,
Dark Tinted Tempered Glass (Black SKU only)

DIMENSIONS

Height (with feet): 435 mm / 17.13 in

Width: 287 mm / 11.3 in

Depth: 415 mm / 16.34 in

Weight: 9.4 kg

COMPATIBILITY & CLEARANCE

CPU Cooler Height: 163 mm / 6.42 in

GPU Length: 365 mm / 14.37 in

PSU Length: 200 mm / 7.87 in

Cable Management: 91 mm / 3.58 in

Top Radiator: 30 mm / 1.18 in

FRONT I/O

USB 3.2 Gen 1 Type-A: 2

USB 3.2 Gen 2 Type-C: 1

Headset Audio Jack: 1

EXPANSION SLOTS

Standard: 7

Vertical: 0

DRIVE BAYS

2.5": 2

3.5": 1

FAN SUPPORT

Front-Right: 3 x 120 mm (3 x F120Q Included)

Top: 3 x 120 mm / 2 x 140 mm

Bottom: 2 x 140 mm

Rear: 1 x 120 mm

Filters: High-Performance Mesh

RADIATOR SUPPORT

Top: Up to 360 mm

Rear: Up to 120 mm

FAN SPECS

Model: F120Q Airflow Fan (Case Version)

Speed: 1200 ± 120 RPM

Airflow: 62.18 CFM

Static Pressure: 1.05 mm-H2O

Noise: 25.1 dBA

Fan Connector: 3-Pin

GENERAL

Warranty: 2 Years

Model Number: CC-H61FW-01 (White) / CC-H61FB-01 (Black)

UPC: 810074844130 (White) / 810074844147 (Black)

EAN: 5056547204048 (White) / 5056547204055 (Black)

INSIDE THE BOX

H6 Flow: 1

F120Q Airflow (Case Version): 3

Installation Accessories: 1

User Guide: 1
