MSI PRO Z890-S WIFI PZ Intel DDR5 PCIE 5.0 LGA 1851 ATX Motherboard
Unlock powerful performance with the MSI PRO Z890-S WIFI PZ motherboard, designed for Intel LGA 1851 processors. This ATX motherboard supports DDR5 memory for lightning-fast speeds and enhanced multitasking. Equipped with WIFI 6E and lightning USB 3.2 Gen 2 ports, it ensures seamless connectivity. Perfect for gamers and creators alike, the robust thermal solutions guarantee stability under heavy workloads. Enjoy optimal gaming and content creation experiences today.
Features
General
SKU | 941-28C-A0B |
Features
Brand | MSI |
Model Number | PRO Z890-S WIFI PZ |
CPU Socket Type | LGA 1851 |
Memory Type | DDR5 |
Form Factor | ATX |
Key Features |
Supports Intel 12th and 13th Gen processors LGA 1851 (Socket V1) compatibility ATX form factor Dual-channel DDR5 memory support Up to 128GB memory capacity Four DIMM slots PCIe 5.0 support for improved graphics and storage Integrated Wi-Fi 6 and Bluetooth connectivity Multiple M.2 slots for high-speed SSDs USB 3.2 Gen 2 ports for fast data transfer Enhanced thermal solutions with heatsinks 2.5 Gigabit LAN for better network performance Audio Boost technology for high-quality sound Customizable RGB lighting support User-friendly BIOS interface for easy setup and management |
Description
MSI PRO Z890-S WIFI PZ motherboard Intel Z890 LGA 1851 (Socket V1) ATX
MSI PRO Z890-S WIFI PZ Motherboard – Unleash Your Computing Power
The MSI PRO Z890-S WIFI PZ Motherboard is designed for the modern user who demands performance and versatility. Featuring the powerful Intel Z890 chipset, this motherboard offers exceptional support for the latest Intel processors on the LGA 1851 (Socket V1). Whether you're a gamer, content creator, or professional, this motherboard ensures a stable and responsive computing experience.
Built on the robust ATX form factor, the PRO Z890-S WIFI PZ provides ample room for expansion while being compact enough to fit in a variety of cases. This motherboard supports high-speed DDR5 memory, enabling your system to run multiple applications smoothly without lag. Unlock the true potential of your rig with speeds reaching up to 6400 MHz and beyond, allowing for faster data processing and improved multitasking capabilities.
Connectivity is key in today’s digital landscape, and the MSZ PRO Z890-S WIFI PZ does not disappoint. Equipped with dual-band Wi-Fi 6E, you can enjoy fast internet speeds and lower latency, perfect for online gaming and real-time collaboration. The integrated Bluetooth 5.2 allows you to connect your devices wirelessly with ease, ensuring you stay connected without the clutter of cables.
Data storage options are plentiful with the MSI PRO Z890-S. It includes multiple M.2 slots for ultra-fast NVMe SSDs, as well as traditional SATA ports to accommodate larger hard drives. This flexibility means you can easily create a hybrid storage solution tailored to your needs. Additionally, the motherboard supports RAID configurations, providing enhanced performance and redundancy for critical data.
Durability and reliability are hallmarks of the MSI PRO Z890-S WIFI PZ. Built with high-quality components and reinforced PCIe slots, this motherboard minimizes the risk of hardware failure and enhances lifespan. The advanced thermal management system ensures optimal airflow and effective heat dissipation, keeping your system cool even during intensive gaming sessions or heavy workloads.
To further enhance your experience, MSI's exclusive software suite provides intuitive control over system settings, allowing you to customize performance and optimize settings effortlessly. The user-friendly BIOS interface gives you direct access to advanced features, putting you firmly in control of your hardware.
From gamers looking to build the ultimate gaming rig to professionals needing a reliable workstation, the MSI PRO Z890-S WIFI PZ Motherboard is the perfect choice. With its combination of performance, connectivity, and expandability, this motherboard positions itself as a top contender in the market.
Upgrade your system today and experience the difference that the MSI PRO Z890-S WIFI PZ can bring to your computing setup. Don't settle for less, equip your build with a motherboard that is engineered to meet the demands of modern computing.
Specification
Chipset
INTEL Z890
CPU
Supports Intel® Core™ Ultra Processors (Series 2)
LGA 1851
Memory
4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Memory Support 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s
Max. overclocking frequency:
• 1DPC 1R Max speed up to 8800+ MT/s
• 1DPC 2R Max speed up to 7200+ MT/s
• 2DPC 1R Max speed up to 6400+ MT/s
• 2DPC 2R Max speed up to 5600+ MT/s
Supports Intel® POR Speed and JEDEC Speed
Supports Memory Overclocking and Intel® XMP 3.0
Supports Dual-Controller Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM
• The DIMM slots on this motherboard have double-sided latches.
• Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on
the product’s Support page or visit https://www.msi.com/support/.
Onboard Graphics
1x HDMI™
Support HDMI™ 2.1, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DisplayPort 1.4, maximum resolution of 4K 60Hz*
1x Type-C DisplayPort
Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz*
*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Slot
4x PCI-E x16 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
PCI_E4 Gen PCIe 4.0 supports up to x4 (From CPU)
Audio
Realtek® ALC897 Codec
7.1-Channel High Definition Audio
Storage
3x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G
*Please refer to the manual for M.2 SSD heatsink restrictions.
RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices
Onboard Thunderbolt
1x Thunderbolt4 ports (Rear)
Supports up to 40Gbps transfer rate with Thunderbolt devices
Supports up to 20Gbps transfer rate with USB4 devices
Supports up to 10Gbps transfer rate with USB 3.2 devices
Supports up to 5V/3A,15W power charging
Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices
Supports up to 8K display
USB
4x USB 2.0 (Front)
6x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
1x USB 20Gbps Type C (Rear)
1x USB 20Gbps Type C (Front)
LAN
Realtek® 8125D 2.5Gbps LAN
Internal IO
1x Thunderbolt5 card connector(JTBT5, support RTD3)
1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
4x System Fan
1x EZ Conn-header (JAF_1)
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Tuning Controller connector(JDASH)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
1x USB 20Gbps Type C ports
WIRELESS LAN & BLUETOOTH
Intel® Wi-Fi 7
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
Supports Bluetooth® 5.4**, MLO, 4KQAM
6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2.
- ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.
- LED FEATURE
4x EZ Debug LED
BACK PANEL PORTS
DisplayPort
USB 5Gbps Type-A
2.5G LAN
Wi-Fi / Bluetooth
Audio Connectors
HDMI™
Thunderbolt™ 4 40Gbps (Type-C)
USB 20Gbps Type-C
USB 5Gbps Type-A
OPERATING SYSTEM
Support for Windows® 11 64-bit
